Fernco Icon Pushfit Couplings are designed to connect drainage pipes for wastewater and rainwater by utilizing the internal surfaces. Unlike traditional flexible couplings that attach to the outside of pipes, these internal Pushfit Couplings are ideal for situations where external access is limited, such as when pipes are encased in concrete or surrounded by brick or other rigid materials. This innovative approach saves time and allows for effective connections using the internal pipe surfaces.
Constructed from materials that meet the latest standards for below-ground applications, these couplings maintain a minimal visual profile when installed, making them suitable for above-ground use as well.
Features & Benefits:
- Greatly reduces labor time when connecting challenging pipes.
- Ensures a watertight seal on any type of pipe material.
- Capable of connecting pipes with varying or irregular outside diameters.
- No need to expose the external surface of the pipe.
- Successfully passes pressure tests.
- Provides protection against shear loads.
- Tool-free installation takes just 30 seconds or less.
-
Sizes: 93-98mm / 99-103mm
Specification Weight 0.21 kg Manufacturer Code ICP95-100 Brand Fernco Colour Black/Blue Material Plastic/Rubber Material Type EPDM Rubber/ABS Plastic Width 117mm Height 110mm Length 117mm
