Introducing the Wrekin B125 Solid Top Slide-Out Ductile Iron Cover & Frame, a sturdy and dependable solution for your infrastructure requirements, crafted to meet the highest safety and performance standards. Suitable for both urban and suburban environments, its robust construction ensures durability and user-friendliness, making it an ideal choice for a variety of applications. With a British Standard Kitemark, you can trust in its quality and adherence to industry regulations.
This cover and frame set features a convenient slide-out design that simplifies lifting and handling, enhancing both efficiency and safety. Its labyrinth seal effectively prevents odours and water ingress, ensuring a clean and functional environment. Additionally, the safety keyway is designed to prevent the accidental disengagement of the lifting key, further improving safety during operation. The product has undergone rigorous testing, achieving a PSRV of over 70 on the top surface of the chequer, guaranteeing reliable performance.
Features & Benefits:
- Complies with BS EN 124:2015 B125 standards, certified with a British Standard Kitemark for Group 2 situations.
- Slide-out design for effortless removal.
- Indexed covers ensure a correct fit every time.
- Labyrinth seal to prevent odour escape and water ingress.
- Safety keyway prevents accidental disengagement.
- PSRV tested at over 70 at the top surface of the chequer by a UKAS accredited third party.
- Durable ductile iron construction.
- Single seal design.
- Flanges: 4
- Application Badging / Customer Badging: Yes / Yes
- Weight Class / Group: B125 / Group 2
- Raised Pattern Area: 60621 mm²
- Seating Depth: 25mm / Depth of Insertion: 25mm
- Available Options: Screw locking, Neoprene seal, Integral badging, Safety grille, Ventilation holes, Flood and odour control plate.
- Dimensions: 600 x 450 x 40mm
Specification Weight 25.00 kg Manufacturer Code DMS1B2/6045/K Brand Wrekin Diameter N/A For Manhole Type Solid Top Material Metal Material Type Ductile Iron Range Safeseal Shape Rectangular Type Manhole cover Length 600mm Thickness 40mm Width 450mm
