Introducing the Unilin Full Fill PIR Cavity Wall Insulation, an innovative solution for traditional wall insulation that excels in both efficiency and performance. Engineered to achieve passive level U-Values as low as 0.12 W/m²K, this insulation offers exceptional thermal bridging detailing in cavities under 150mm wide, making it a vital component for any construction project focused on maximizing energy efficiency and comfort.
This high-performance composite board is crafted from enhanced PIR with a lambda value of 0.021 W/mK, specifically designed for full-fill cavity wall applications. Its engineered HIPs facer provides robust protection against wind-driven rain, while pre-positioned slots for wall ties help to prevent any creep.
The product complies with the FEES 2014 Part L requirements and achieves zero carbon performance within a traditional cavity width, making it an environmentally friendly option for modern building standards.
Features & Benefits:
- High-performance composite board made from enhanced PIR.
- Perfectly suited for full-fill cavity wall applications.
- Engineered HIPs facer for effective protection against wind-driven rain.
- Pre-positioned slots for sloping wall ties to prevent creep.
- Excellent thermal bridging performance.
- Moisture is redirected to the outer surface.
- Fully engineered jointing system, eliminating the need for taping.
- Meets FEES 2014 Part L and achieves zero carbon performance within a traditional cavity width.
- A comprehensive range of accessory pieces is available to create a continuous system.
- Achieves U-Values as low as 0.12 W/m²K.
- Lambda value of 0.021 W/mK.
- Coverage of 0.54 m² per board.
- Dimensions: 1200mm x 450mm x 125mm.
Specification Weight 2.63 kg Manufacturer Code CT/PIR/125/BD/CP01 Brand Unilin Insulation Material Type Polyisocyanurate Width (Imperial) 1ft 6in Length 1200mm Thickness 125mm Width 450mm Fire Classification N/A
